*Test Conditions (Full Charge Range): open flat roads / windless / level 1 / 70kg rider.
*Total Weight: with rack and fender, without pedals and kickstand.
Specifications
Color
Wheel size
Rider's height
Frame
Aluminum 6061, Powder coated
Fork
Carbon fiber
Drivetrain
Chain drive
10S, 38t, shimano deore 11-42t
Belt drive
Single speed, Gates CDX 50-19t
Smartpac
Battery capacity
540Wh
Output charging
USB type A/C, max 65W
Motor controller
36V 250W
IoT
LTE Cat.1 / GPS / Bluetooth
Range
Up to 100km *
Charging time
3.5h
Control mode
Connected to phone via app
Dual mode hub
Duo clutch, inner rotor motor, 40Nm, assistance speed 25km/h, 36H, disc
Lock system
Electronic rear hub lock
Weight
15kg (bike) *, 3kg (smartpac)
Color
Wheel size
Rider's height
Frame
Aluminum 6061, Powder coated
Fork
Carbon fiber
Drivetrain
Chain drive
10S, 38t, shimano deore 11-42t
Belt drive
Single speed, Gates CDX 50-19t
Smartpac
Battery capacity
540Wh
Output charging
USB type A/C, max 65W
Motor controller
36V 250W
IoT
LTE Cat.1 / GPS / Bluetooth
Range
Up to 100km *
Charging time
3.5h
Control mode
Connected to phone via app
Dual mode hub
Duo clutch, inner rotor motor, 40Nm, assistance speed 25km/h, 36H, disc
Lock system
Electronic rear hub lock
Weight
15kg (bike) *, 3kg (smartpac)
Color
Wheel size
Rider's height
Frame
Aluminum 6061, Powder coated
Fork
Carbon fiber
Drivetrain
Chain drive
10S, 38t, shimano deore 11-42t
Belt drive
Single speed, Gates CDX 50-19t
Smartpac
Battery capacity
540Wh
Output charging
USB type A/C, max 65W
Motor controller
36V 250W
IoT
LTE Cat.1 / GPS / Bluetooth
Range
Up to 100km *
Charging time
3.5h
Control mode
Connected to phone via app
Dual mode hub
Duo clutch, inner rotor motor, 40Nm, assistance speed 25km/h, 36H, disc
Lock system
Electronic rear hub lock
Weight
15kg (bike) *, 3kg (smartpac)
Handlebar
Aluminum, 640mm
Stem
Aluminum, 80mm, +3°
Saddle
Selle Royal, sport/comfy
Sport seatpost
Aluminum
Aluminum, 30mm travel, combined with comfy saddle
Grip
Ergonomic rubber grip, lockring
Brake
4 piston, hydraulic disc, 160mm rotor
Mudguard
Plastic
Rack
Aluminum, combined with the rear mudguard
Kickstand
Aluminum
Front light
K mark, 20lux, 4500mah 21700 cell
Rear light
K mark, brake high light
Bottom bracket
BSA 73
Crankset
Aluminum, hollowtech
Pedals
Nylon flat pedals
Front hub
Aluminum, 32H, disc
Rim
Aluminum
Display
Bluetooth, LCD screen, 100dB beeper
*Test Conditions (Full Charge Range): open flat roads / windless / level 1 / 70kg rider.
*Total Weight: with rack and fender, without pedals and kickstand.
